Working Principle of Electric Torque Spanner Which Brand is Better

　　电动扭矩扳手哪个牌子好

　　Which brand of electric torque wrench is better

　　济南万中电动扳手有限公司--电动扭矩扳手,扭剪电动扭矩扳手,扭剪型电动扭矩扳手电动扭剪扳手致力于钢结构安装（高强螺栓）工具的配套服务，坚持“以客户为中心”的理念，坚持“领域”，积极为客户创造价值。

　　Jinan Wanzhong Electric Spanner Co., Ltd. - Electric Torque Spanner, Electric Torque Spanner, Electric Torque Spanner, Electric Torque Spanner Experts are dedicated to supporting services of steel structure installation (high strength bolt) tools, adhere to the concept of "customer-centered", adhere to the "professional field", and actively create value for customers.

　　主要产品有：扭剪型电动扭矩扳手、定扭矩电动扭矩扳手、电动扭剪扳手、扭剪扳手、扭矩型初终紧电动扭矩扳手、初紧电动扭矩扳手，高速风动扳手以及手动检查扳手，广泛用于铁路和桥梁、锅炉钢结构、高层建筑、工业厂房、电厂建设、体育场馆城市轨道交通等。

　　The main products are: Torsion-shear electric torque wrench, fixed-torque electric torque wrench, electric Torsion-shear wrench, Torsion-shear wrench, torsion-type initial and final tightening electric torque wrench, initial tightening electric torque wrench, high-speed pneumatic wrench and manual inspection wrench, which are widely used in railway and highway bridges, boiler steel structure, high-rise buildings, industrial plants, power plant construction, stadium urban track. Traffic and so on.

　　电动扭矩扳手工作原理

　　Working Principle of Electric Torque Wrench

　　原理是在扳手旋转的同时，有类似于手锤一样的东西在上面频繁的敲击，原理和电锤相似

　　The principle is that while the wrench rotates, something similar to the hammer strikes frequently on it. The principle is similar to the electric hammer.

　　液压扭矩扳手主要用于化工冶金，船厂方面，质量轻，使用寿命长，的制作工艺，品质高，优

　　Hydraulic torque wrench is mainly used in chemical metallurgy, shipyard, light weight, long service life, advanced manufacturing technology, high quality, excellent price.

　　电动扭矩扳手又名气动拉铆枪或气动拉钉机或气动铆钉枪或气动抽芯铆钉枪,叫法不一,是目前国内的铆接工具。

　　Electric torque wrench, also known as pneumatic riveting gun or pneumatic riveting machine or pneumatic riveting gun or pneumatic core-pulling riveting gun, has different names. It is an advanced riveting tool in China.

　　电动扭矩扳手工作原理

　　Working Principle of Electric Torque Wrench

　　电动扭矩扳手以压缩空气为动力,通过各个汽缸的串联以达到拉断铆钉的目的,具有拉铆方便,铆接速度快、手持重量轻、无油液损耗等优点。

　　The electric torque wrench is driven by compressed air and can break rivets by connecting cylinders in series. It has the advantages of convenient riveting, fast riveting speed, light hand weight and no oil loss.

　　用途

　　purpose

　　主要用于铝,铁,不锈钢板材的铆接。不锈钢/合金钢拉钉嘴。主要是汽动拉钉,枪拉钉速度快。油压式结构,拉钉力量大。气动拉铆枪广泛适用于装饰装潢、汽车制造及改装、集装箱、电器、家电、仪表、箱包和机械制造等行业,是目前国际比较的铆接工具之一,目前国内适用量居多的气动拉钉枪主要来自台湾、日本。

　　Mainly used for riveting of aluminium, iron and stainless steel sheets. Stainless steel/alloy steel pull nail nozzle. Mainly is the pneumatic pulling nail, gun pulling nail fast. Hydraulic structure, pull nail strength. Pneumatic riveting gun is widely used in decoration and decoration, automobile manufacturing and modification, container, electrical appliances, household appliances, instrumentation, bags and machinery manufacturing industries. It is one of the most advanced riveting tools in the world. At present, the most widely used brand of pneumatic riveting gun in China mainly comes from Taiwan and Japan.

　　适用范围

　　Scope of application

　　1.铝门窗制造业

　　1. Manufacturing of Aluminum Doors and Windows

　　2.计算机外壳

　　2. Computer Shell

　　3.电子制造业

　　3. Electronic Manufacturing Industry

　　4.其他各种铆接作业

　　4. Other riveting operations

　　功能

　　function

　　一、振动技术提供了从工作环境改造学来说正确的动作,拉钉枪(积累性损伤障碍)的危险性降到比较小化。特别针对1/4Magna-Lok结构铆钉、超过3700磅的牵引力、耐受力强的压铸结构以适用于粗糙不平的地方铆钉直径(mm):4.8/6.4(均适用各材质铆钉)比较大工具拉伸力N(kgf):16637(1700)比较大行程(mm):22.0所需气压MPa(kgf/cm):0.59-0.64(6.0-6.5)每根铆钉所需的空气量:4.6L/铆钉重量(kg):2.9另外360度旋转气密接合可使工具在工作地点垂直放置比较适合用于被广泛使用的直径2.4到直么4.8的铆钉的铆接作业,长行程化(14-16mm)的设计,大幅扩大了一次性开机的铆接范围,而且速度较以往产品有所提高。


　　1. Vibration technology provides correct action from the perspective of work environment renovation, and the risk of nail-pulling guns (cumulative damage barriers) is minimized. Particularly for 1/4 Magna-Lok structure rivets, more than 3700 pounds of traction force, high tolerance die-casting structure to be suitable for rough areas rivet diameter (mm): 4.8/6.4 (all suitable for rivets of various materials) maximum tool tension N (kgf): 16637 (1700) maximum stroke (mm): 22.0 pneumatic MPa (kgf/cm): 0.59-0.64 (6.5) per rivet required air volume: 4.6L/rivet weight (kg): 2.9 and 360 degrees. Rotary air-tight joint can make tools placed vertically in the workplace most suitable for riveting operations of rivets with diameters of 2.4 to 4.8, which are widely used. The design of long stroke (14-16 mm) greatly enlarges the riveting range of one-time start-up, and the speed is higher than that of previous products.

　　二、自动吸钉,拉钉速度比一般快一倍。自动退钉,连续拉钉作业,不必倒钉,即省时间。采用航空铝材料,轻巧,长时间使用无疲劳感。可调节拉力大小,速度快慢。

　　Second, automatic nail suction, nail pulling speed is twice as fast as usual. Automatic nail withdrawal, continuous nail pulling operation, do not need to reverse nail, that is to save time. Aircraft aluminium material, lightweight, long-term use without fatigue. Adjustable tension, speed.
