Torque wrench calibration instrument operation method, SGXJ Torque wrench calibrator is used to calibrate the torque wrench tester. Torque wrench calibrator is a high performance test instrument, which has been widely used in power, light industry, machinery, engine, internal combustion engine, electric vehicle, motorcycle, automobile, ship, aircraft and other manufacturing and measurement and testing departments.

　　大家知道扭矩扳手校准器的操作方法吗?-电动扭矩扳手:https://www.xjnwz.com

　　Do you know how to operate the torque wrench calibrator? - Electric torque wrench: https://www.xjnwz.com

　　扭矩扳手校准器的操作方法

　　Operation Method of Torque Spanner Calibrator

　　1. 使用扭矩扳手校准仪前，应检查仪器电量是否充足。如电量不足，请先充电(充电时也可使用)。

　　1. Before using the torque wrench calibrator, check whether the power of the instrument is sufficient. If the electricity is insufficient, please charge it first (it can also be used when charging).

　　2. 将被测件的被测头放入被测件的被测孔内，用被测件另一端的手柄置于高度调节块上方(如长度不足，可自由调节整个加载装置)。

　　2. Put the measured head into the tested hole, and place the handle at the other end of the measured piece above the height adjustment block (if the length is insufficient, the whole loading device can be adjusted freely).

　　3.打开电源开关，显示的转矩值为零。如果不为零，按“复位”按钮复位扭矩值。

　　3. Turn on the power switch and the display torque is zero. If it is not zero, press the "reset" button to reset the torque value.

　　4. 测试前，设置上下限、比较小存储值、比较小峰值保持值、自动峰值时间、自动关机时间、重力加速度等。

　　4. Before testing, upper and lower limits, minimum storage value, minimum peak holding value, automatic peak time, automatic shutdown time, gravity acceleration and so on are set.

　　(1)上限设置:用户设置上限，可根据需要自由设置。当达到上限时，表示自动声光提示，上限不高于全量程。

　　(1) upper limit setting: users can set the upper limit freely according to their needs. When the upper limit is reached, it means automatic acoustooptic prompt, and the upper limit is not higher than the full range.

　　(2)下限设置:用户根据需要自由设置下限。当达到下限时，表示自动照明提示。下限不得高于规定的上限。

　　(2) Lower Limit Setting: Users are free to set the lower limit according to their needs. When the lower limit is reached, the automatic illumination prompt is indicated. The lower limit shall not exceed the prescribed upper limit.

　　(3)比较小存储值设置:用户根据存储需求设置比较小存储值。小于此值的数据将不存储。

　　(3) Minimum Storage Value Settings: Users set Minimum Storage Value according to storage requirements. Data less than this value will not be stored.

　　(4)比较小峰值设置:用户需要根据峰值设置自动测峰，小于峰值的数据不会被峰值保存。

　　(4) Minimum Peak Settings: Users need to set automatic peak measurement according to the peak value. Data smaller than the peak value will not be saved by the peak value.

　　(5)自动峰值时间设定:用户可根据自动峰值测量状态，自由设定1秒99秒的峰值时间。

　　(5) Automatic peak time setting: users can freely set the peak time from 1 second to 99 seconds according to the automatic peak measurement status.

　　大家知道扭矩扳手校准器的操作方法吗?-电动扭矩扳手:https://www.xjnwz.com

　　Do you know how to operate the torque wrench calibrator? - Electric torque wrench: https://www.xjnwz.com

　　6、自动关机时间设置:在无运行状态下，可自由设置0分钟9分钟的自动关机时间(设置为0分钟时，表示取消自动关机)。

　　6. Automatic shutdown time settings: In the non-operating state, the automatic shutdown time can be set freely from 0 minutes to 9 minutes (set to 0 minutes, which means canceling the automatic shutdown).

　　7、重力加速度设置:用户可以根据该区域的位置设置重力加速度值，默认为9.794。

　　7. Gravity acceleration settings: Users can set the value of gravity acceleration according to the location of the area, default is 9.794.

　　今天恢复初始设置:用户操作不当或多次更改数据混淆，可以通过此设置将1 ~ 7个数据恢复到出厂状态。以上 是电动扭矩扳手为大家整理的相关内容，想要了解更多内容，欢迎访问我们网站：https://www.xjnwz.com

　　Restore the initial settings today: Users can restore 1 to 7 data to factory status through improper operation or multiple changes in data confusion. These are the related contents of the electric torque wrench for you. For more information, please visit our website: https://www.xjnwz.com.
