剪扳手的定义:
Definition of shear wrench:
扭剪扳手是一种终紧扭剪型高强度螺栓的工具,一般有电动扭剪扳手和手动扭剪扳手,其中电动扭剪扳手比较常见。
Torsional shear wrench is a tool for final tightening of torsional shear type high-strength bolts. Generally, there are electric torsional shear wrench and manual torsional shear wrench, among which electric torsional shear wrench is more common.
扭剪扳手的应用:
Application of torsion shear wrench:
扭剪型高强螺栓的初紧可使用冲击电动扳手或定扭矩扳手,而终紧需要使用扭剪扳手,所以扭剪扳手是专门终紧扭剪型高强螺栓的。
The initial tightening of torsional shear high-strength bolts can use impact electric wrench or constant torque wrench, while the final tightening requires torsional shear wrench, so the torsional shear wrench is specially used for the final tightening of torsional shear high-strength bolts.
扭剪扳手的使用:
Use of torsion shear wrench:
扭剪扳手主要是终紧扭剪型高强螺栓的,它的目的就是把扭剪型高强螺栓的梅花头打断即可。工作时将扳手头对准螺栓头,扣动开关即可开始工作,几秒后,螺栓梅花头将被扭断,然后抽出扳手扣动扳机将梅花头弹出,即结束工作。
The torsional shear wrench is mainly used to finally tighten the torsional shear high-strength bolt, and its purpose is to break the plum blossom head of the torsional shear high-strength bolt. When working, align the wrench head with the bolt head, and then pull the switch to start working. After a few seconds, the bolt Torx head will be broken, and then pull out the wrench to pull the trigger to eject the Torx head, which is the end of the work.
扭剪扳手的特点:
Characteristics of torsion shear wrench:
操作方便、省时省力、方便。
It is easy to operate, time-saving, labor-saving, safe and convenient.
扭剪扳手主要用于紧固钢结构工程中的扭剪型高强度螺栓。 扭剪螺栓分为六个标准螺栓M16-20-22-24-27-30。扭剪扳手的应用:扭剪式高强度螺栓的初始拧紧可以使用冲击电动扳手或固定扭矩扳手,而更终拧紧则必须使用扭剪扳手,因此扭剪扳手专门用于扭剪的更终拧紧 型高强度螺栓。
Torsional shear wrench is mainly used to fasten torsional shear high-strength bolts in steel structure engineering. Torsional shear bolts are divided into six national standard bolts m16-20-22-24-27-30. Application of torsional shear wrench: the initial tightening of torsional shear high-strength bolts can use impact electric wrench or fixed torque wrench, while the final tightening must use torsional shear wrench. Therefore, torsional shear wrench is specially used for the final tightening of torsional shear high-strength bolts.
