电动扳手是以“电”为驱动力的扳手，是指拧紧和拆卸螺栓及螺母的电动工具，是一种拧紧高强度螺栓的工具。用于钢结构桥梁、厂房建筑、化工、发电设备安装大六角头高强度螺栓施工的初拧、终拧和扭剪型高强度螺栓的初拧，以及对螺栓紧固件的扭矩或轴向力有严格要求的场合。
Electric wrench is a wrench driven by "electricity". It refers to an electric tool for tightening and removing bolts and nuts. It is a tool for tightening high-strength bolts. It is used for the initial tightening and final tightening of large hexagon head high-strength bolts in the construction of steel structure bridges, factory buildings, chemical industry and power generation equipment, and the initial tightening of torsional shear type high-strength bolts, as well as the occasions where there are strict requirements on the torque or axial force of bolt fasteners.
从结构来说，电动扳手有离合器式和冲击式两种结构型式。
In terms of structure, the electric wrench has two types of structure: safety clutch type and impact type.
从电源来分，电动扳手可分为：带电池的电动扳手、插220V电源的电动扳手。
In terms of power supply, electric wrenches can be divided into: electric wrenches with batteries and electric wrenches with 220V power supply.
其中带电池的电动扳手体积小重量轻、使用方便，但是扭矩小，一般用来打普通螺丝。而插220V电源的电动扳手相对来说比带电池的电动扳手要重，还大，主要是扭矩大，可以紧固高强螺栓。以下几种电动扳手都是插电源的电动扳手。
The electric wrench with battery is small in size and light in weight, convenient in use, but small in torque, and generally used to make ordinary screws. The electric wrench with 220V power supply is relatively heavier and larger than the electric wrench with battery, mainly because of its large torque, which can fasten high-strength bolts. The following electric wrenches are all electric wrenches plugged into the power supply.
冲击电动扳手就是常说的普通电动扳手，主要是初紧螺栓的,它的使用很简单,就是对准螺栓扳动电源开关就行。
The impact electric wrench is often called an ordinary electric wrench. It is mainly used to tighten the bolts for the first time. It is very simple to use, that is, pull the power switch against the bolt.
扭剪电动扳手主要是终紧扭剪型高强螺栓的,它的使用就是用扳手套筒对准螺栓梅花头，扳动电源开关,直到把扭剪型高强螺栓的梅花头打断为止。常见的扭剪电动扳手是枪式的，也有角向的。
The electric wrench for torsional shear is mainly used to tighten the torsional shear type high-strength bolt. It is used to align the wrench socket with the bolt box head and turn the power switch until the box head of the torsional shear type high-strength bolt is broken. The common electric wrench for twist shear is gun type and also angular.
定扭矩电动扳手既可初紧又可终紧,它的使用是先调节扭矩,再紧固螺栓。常见的定扭矩电动扳手也是枪式的，也有角向的。
The fixed torque electric wrench can be used for initial tightening and final tightening. It is used to adjust the torque first, and then tighten the bolts. The common constant torque electric wrench is also gun type and angular.
转角法电动扳手主要也属于定扭矩扳手的一种,它的使用是先调节旋转度数,再紧固螺栓。
The angle method electric wrench is also a kind of constant torque wrench. It is used to adjust the rotation degree first, and then tighten the bolts.
角向电动扳手是一种专门紧固钢架夹角部位螺栓的电动扳手,它的使用和其他前田电动扳手原理一样。
The angle electric wrench is an electric wrench specially used to fasten the bolts at the angle of the steel frame. Its use principle is the same as that of other Maeda electric wrenches.
超大扭矩电动扳手，一般是带倍增器，也有本身就达到10000Nm以上的定扭矩电动扳手扳手。
The super torque electric wrench is generally equipped with a multiplier, and there are also constant torque electric wrench wrenches that can reach 10000Nm or more.
数显电动扳手属于定扭矩电动扳手，本身带着显示仪，是可以直接读取扭矩值数据的电动扳手。
Digital display electric wrench belongs to constant torque electric wrench, with a display, which can directly read torque data.
施工现场注意事项：
Safety precautions on construction site:
1)在接通电源前，需要检查开关处于断开状态才能插入。
1) Before turning on the power, check that the switch is disconnected before inserting it.
2)确认现场所接电源与电动扳手所需要电压是否相符，是否接有漏电保护器。
2) Confirm whether the on-site power supply is consistent with the voltage required by the electric wrench, and whether there is a leakage protector connected.
3)根据螺母大小选择匹配的套筒，并妥善安装。
3) Select the matching sleeve according to the nut size and install it properly.
4)电压过高过低均不宜使用。
4) If the voltage is too high or too low, it should not be used.
5)不要将简体当做锤击工具使用。
5) Do not use Simplified Chinese as a hammer tool.
6)不要在手摇杆上增加套杆或撬棒后加力。
6) Do not apply force after adding a sleeve or crowbar to the hand crank.
7)电动扳手的金属外壳需要可靠接地。
7) The metal shell of the electric wrench shall be reliably grounded.
8)检查电动扳手机身安装螺钉紧固情况，如果发现螺钉松了，需要立即重新扭紧。
8) Check the fastening of the mounting screws on the body of the electric wrench. If the screws are found to be loose, retighten them immediately.
9)检查手持电动扳手两侧手柄是否完好，安装是否牢固。
9) Check whether the handles on both sides of the hand-held electric wrench are intact and firmly installed.
10)站在梯子上工作或高处作业应做好防止高处坠落措施。
10) Measures shall be taken to prevent falling from heights when working on ladders or at heights.
11)如果作业场所在远离电源的地点，需延伸线缆时，需要使用容量足够、安装合格的延伸线缆。
11) If the work place is far away from the power supply, the extension cable with sufficient capacity and qualified installation shall be used.
普通套筒、精品套筒、防爆套筒、气动套筒、风动套筒、重型套筒、套装套筒、加重套筒、加长套筒、大规格国产套筒、进口套筒、扭剪套筒、双联套筒、扭矩扳手专用套筒，各种尺寸套筒。
Ordinary sleeve, high-quality sleeve, explosion-proof sleeve, pneumatic sleeve, pneumatic sleeve, heavy sleeve, suit sleeve, weighted sleeve, extended sleeve, large-sized domestic sleeve, imported sleeve, torsional shear sleeve, duplex sleeve, special sleeve for torque wrench, and sockets of various sizes.
