扭矩扳手检定仪功能特点：
Functional features of torque wrench calibrator:
1、高精度、高分辨率、采样速度快、全屏显示，7寸触摸屏显示。
1. High precision, high resolution, fast sampling speed, full screen display, 7-inch touch screen display.
2、采用高精度扭矩扳手，具有扭矩方向显示。
2. High precision torque wrench is adopted, with torque direction display.
3、上下限值的设定，红绿指示灯及峰鸣器声光报警。
3. The setting of upper and lower limits, red and green indicators and audible and visual alarm of buzzer.
4、三种单位互相转换，可供选择（N·m、kgf·cm、Ib·in）。
4. The three units are converted to each other and can be selected (n · m, KGF · cm, IB · in).
5、实时、峰值、自动峰值三种模式可随意切换。
5. Real time, peak and automatic peak modes can be switched at will.
6、采用仪表显示、曲线显示、曲线缩放功能、全触摸屏显示。
6. Instrument display, curve display, curve scaling function and full touch screen display are adopted.
7、峰值保持、自动解除功能、解除时间自由设定。
7. Peak holding, automatic release function and release time can be set freely.
8、存储大量测试数据。
8. Store a large amount of test data.
9、无操作自动关机功能，时间可自由设定。
9. There is no automatic shutdown function, and the time can be set freely.
一、 扭剪扳手如何正确使用
1、 How to use twist shear wrench correctly
1.设定所需的扭矩值，并将锁紧装置拨 lock 位置；
1. Set the required torque value and turn the locking device to the lock position;
2.从小值往大值方向调整扭矩，若超过设定值，往回调低于设定扭矩值后再进
2. Adjust the torque from small value to large value. If it exceeds the set value, adjust it back to lower than the set torque value before entering
行调整；
Line adjustment;
3.检查驱动头是否适合，或选用合适的转接头；
3. Check whether the driving head is suitable, or select a suitable adapter;
4.使用后需将设定值转回小刻度位置；
4. Turn the set value back to the small scale position after use;
5.握把正中间为施力位置；
5. The middle of the grip is the force application position;
6.施力前请先确定扳手与被施力的物体确实结合；
6. Before applying force, please make sure that the wrench is really combined with the object to be applied;
7.施力应平稳缓慢，听到音响即待弹簧释放后，即停止施力；
7. The force application shall be steady and slow. When the sound is heard, stop the force application after the spring is released;
二、 扭剪扳手故障出现的原因
2、 Causes of failure of torsional shear wrench
1.自锁功能无法进行调节，发生这种情况往往是由于量程调节超出了量程；
1. The self-locking function cannot be adjusted, which often occurs because the range adjustment exceeds the range;
锁定键反向过紧。
The locking key is too tight in the reverse direction.
2.超出量没有作声响，发生这种情况的原因是方向调整纽拔错位。
2. There is no sound in excess. The reason for this is the dislocation of the direction adjustment button.
3.扭剪接头打滑，这种情况是由于连接头未装到位；方向转换纽未拔到位。
3. The torsion shear joint slips, which is because the connector is not installed in place; The direction change-over button is not pulled in place.
4.扭剪值无法调整，这种情况往往是紧锁键处于自锁状态。
4. The torsional shear value cannot be adjusted. In this case, the locking key is often in the self-locking state.
