Also known as a torque plate or torque plate, torque is the product of force and distance. When tightening ribbed fasteners such as screws, bolts, and nuts, it is necessary to control the magnitude of the applied torque to ensure that the ribs are tightened and not damaged due to excessive torque. Therefore, a torque plate is used for operation. Firstly, set the maximum torque value required. When the applied torque reaches the set value, the board will emit "chatter" or bend a little angle at the connection of the board, indicating that it has been tightened and no more force should be applied.

具有预设扭矩数据和动静安装。当紧固件的拧紧扭矩抵达预设数据时，能自动拍发信号"卡嗒"（click）的一声，一同伴有明显的手抚摸时的感觉振荡，提示结束作业。免除效用力后，板子各相关零件能自动复位。

Equipped with preset torque data and dynamic and static installation. When the tightening torque of the fastener reaches the preset data, it can automatically send a signal of "click", accompanied by a noticeable oscillation of hand touch, indicating the end of the operation. After eliminating effective force, all relevant parts of the board can automatically reset.

二可切换二种方向。拨转棘轮转向开关，板子可逆时针加力。

Two directions can be switched. Turn the ratchet steering switch and apply force to the board in a reversible clockwise direction.

公英制（N.mlbf.ft）双刻度线；手柄微分刻度线。读数明晰精确。

Metric English (N.mlbf.ft) double scale mark; Handle differential scale mark. The reading is clear and accurate.

硼钢资料锻制，坚忍经用，生计的年限长 。校准追溯西方强国技术标准学会（NBS）。

Made of boron steel materials, it is durable and has a long lifespan. Calibration can be traced back to the Technical Standards Society (NBS) of Western countries.

精确度符合 ISO 6789：1992. ASME B107.14 , GGG - W-68.

Accuracy in accordance with ISO 6789:1992 ASME B107.14 , GGG - W-68.

按照工件所需扭矩值要求，确定预设扭矩值。

Determine the preset torque value according to the required torque value requirements of the workpiece.

二预设扭矩值时，将板子手柄上的确定环下拉，一同转动手柄，调度标尺主刻度线和微分刻度线数据所需扭矩值。调度好后，松开确定环，手柄自动确定。

When setting two preset torque values, pull down the determining ring on the board handle and rotate the handle together to schedule the data of the main and differential scale lines of the scale to the desired torque value. After scheduling, release the confirmation ring and the handle will automatically confirm.

在板子方榫上装上响应标准套筒，并套住紧固件，再在手柄上缓慢用力。施加外力时必须按标明的箭头方向。当拧紧到拍发信号"卡嗒"（click）的一声（已抵达预设扭矩值），间断加力。一次作业结束。

Install a response standard sleeve on the square tenon of the board, cover the fastener, and then slowly apply force on the handle. When applying external force, it is necessary to follow the indicated arrow direction. When the torque is tightened to a signal of "click" (reaching the preset torque value), the force is applied intermittently. End of one assignment.

大标准扭矩板子使用时，可外加接长套杆以便操作省力。

When using a large standard torque board, an extension sleeve rod can be added for labor-saving operation.

如长时间不必，调度标尺刻线退扭矩更小数据处。

If it is not necessary for a long time, adjust the scale line back to the minimum torque data point.

1订做要求：付款方式：先付30%的订

1. Customization requirements: Payment method: 30% of the order must be paid in advance

2出货前付清剩余70%的余款

2. Pay the remaining 70% before shipment

3我们是不收取样板费

We do not charge sample fees

4订做时间为：收到30%的订后7天货期

4. Customization time: 7 days after receiving 30% of the order

5如有疑问请在线客服.

If you have any questions, please contact online customer service
