打开电池盒后盖，正朝前，装好电池，拧紧后盖。将扳手方榫套入相应尺寸规格得套筒，将套筒装入螺母或螺栓头上

Open the back cover of the battery box, facing forward, install the battery, and tighten the back cover. Insert the square tenon of the wrench into the corresponding size and specification of the socket, and install the socket onto the nut or bolt head

【开启电源】：按【开机】键液晶屏显示读数0000后即可使用

[Power on]: Press the [Power on] button and the LCD screen will display a reading of 0000 before use

【预置】：按【模式】键，使工作状态变为预置状态，根据检测扭矩值得大小，

【 Pre setting 】: Press the 【 Mode 】 key to change the working state to a preset state. Depending on the detected torque value,

按【设定】键,显示PP.PH,再按此键确认后,进入预置报警设定菜单,按模式键(-),【单位】键(+),每次一个单位。

Press the [Set] button to display the PP PH, press this key again to confirm and enter the preset alarm setting menu. Press the mode key (-) and the unit key (+), one unit at a time.

输入预置值,按设定键确认后退出菜单。加力当预置灯点亮同时报警声响起时，表示紧固力矩预定值，可以停止加力。

Enter the preset value, press the set button to confirm, and then exit the menu. When the preset light is on and the alarm sounds, it indicates the predetermined tightening torque value and can stop applying force.

【校零】：扳手自然水平放置状态下，短按【开机】键，显示0000。

【 Zero calibration 】: When the wrench is naturally placed horizontally, short press the 【 Power on 】 button to display 0000.

【单位选择】：根据使用要求，按"单位"键，选择扭矩单位N.m、Ibf.ft、Ibf.in。单位选择：根据使用要求，按"【单位】键，选择扭矩单位N.m、Ibf.ft、Ibf.in。

【 Unit Selection 】: According to the usage requirements, press the "Unit" button to select torque units such as N.m, Ibf.ft, and Ibf-in. Unit selection: According to the usage requirements, press the 【 Unit 】 button to select torque units such as N.m, Ibf.ft, and Ibf-in.

【峰值】：按【模式】键，使工作状态变为峰值保持状态，所施加得大力矩在卸力好继续显示在液晶屏上，时短按【开机】键。

【 Peak 】: Press the 【 Mode 】 button to change the working state to a peak holding state. The applied large torque will continue to be displayed on the LCD screen after unloading. When clearing, press the 【 Power 】 button briefly.

【关机】：a,自动关机：当未检测扭矩值时，3分钟后自动关机。

[Shutdown]: a. Automatic shutdown: When the torque value is not detected, it will automatically shut down after 3 minutes.

手动关机：按【开机】键3秒，即可手动关机。

Manual shutdown: Press the power button for 3 seconds to manually shut down.
